Non Fried Instant Noodles Processing Line
Brand:GELGOOG MACHINERY
Pay Method: WEST UNION L/C T/T CASH
Warranty Time: 12 Months
Loading Port: Qingdao Port
Country Of Origin: China
The Description of Non Fries Instant Noodle Production Line
Non fried instant noodle processing line adopts advanced technology, high degree of automation, with reasonable layout and easy maintenance. The produced instant noodle is of high quality and good taste. This plant uses automatically temperature control, which ensures the original color of the noodle flavor and nutritional composition. Is ideal equipment for non-fried instant noodle production.
Production Flow Chart of Non Fries Instant Noodle Processing Line
Flour mixing →Curing(about 20 minutes)→Composite continuous rolling→noodles steaming→ frame cutting→folding →drying→cooling → packing
As for the production capacity, the non-fried noodle lineusually can produce 80,100 or 160, 200 thousand packs of instant noodles every 8 hours. Adopting advanced technology for nutrient and instant foodstuff complete lines, these instant noodle making machines areinnovative with advanced structure, excellent performance and reliable quality that provide an ideal choice for the investor in foodstuff industry.
Technical Data:
| No. | Machine Name | Model | Quantity | Note |
| 1 | Brine quantifier and mixer | GG10 | 1 SET |
Power:0.75KW,Volume:100L/SET The parts connect with water are made of stainless steel |
| 2 | Double speed dough mixer | GG200 | 1 SET |
Power 9/11 kw,200kg/pot/manual door opening The parts connect with flour are made of stainless steel |
| 3 | Disc cooker machine | GG200 | 1 SET |
Power:4kw,size of pan:Diameter1800mm*410mm The parts connect with flour are made of stainless steel (Make sure the flour after mixing can be absorbed and mixed well) |
| 4 | Composite and continuous dough pressing machine | GG7-50 | 1 SET |
Dough width 350mm,power 5.5kw+5.5kw=11kw 7 sets steel roller,frame is made of steel structure(frequency control) Diameter of roller:diameter 180*2,diameter 240*2,diameter180*2,diameter 162 |
| 5 | Single layer | GG50 | 1 SET |
16 meter,water sealing Main motor power 1.5kw(frequency control),Pan 0.37kw*2,stainless steel |
| 6 | Cutting,folding and conveying machine | GG80 | 1 SET | Main power 1.5kw+0.75kw,cutting blade 50 times/min,adjustable |
| 7 | Double layers drying machine | GG50 | 1 SET | Main motor power 1.5kw*2(frequency control+fan 5.5kw*4,net width:2 meters, total length:30m),stainless steel net |
| 8 | Horizontal conveyor | GG63 | 1 SET | Main motor power 0.37kw |
| 9 | Cooling conveyor | GG63 | 1 SET | One horizental:0.55kw,fan 0.37kw*4 ,length:6 meters.width:0.50 meter, Belt is made of stainless steel |
| 10 | Electricity control cabinet | GG-1 | 1 SET | Main program adopts frequency control, PLC program control |
| Total power | About 55kw |
